KFI Winch Mount 4505-1006

$100.95

Winch mount for select models. Check winch compatibility.

Plate constructed of 3/16" steel
Fairlead bracket constructed of 1/4" steel
Metal bead blasted before powder coated for the best possible finish prep and durability
Very easy to install
Complete installation instructions and mounting hardware included
100% made in USA
Roller fairlead and winch not included.
Designed to work with the following winches:
KFI: ST17 / A2000 / A2500-R2 / A3000 / U45-R2 / U45w-R2 / SE25 / SE35 / SE45-R2 / SE45w-R2 (U45w-R2 and SE45w-R2 will NOT work on 2014-19 models)
KFI: AM-25 / AM-35 / AS-25 / AS-35 / AS-50 / AS-50w
WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
WARN: RT15 / RT25 / RT30 / XT15 / XT25 / XT30 / RT40 / XT40
WARN: Vantage 2000-3000 lb (will NOT work with Vantage 4000 due to motor lead orientation)
WARN: ProVantage 2500-4500 lb (ProVantage 3500 and 4500 will require lead rotation)
RAMSEY: ATV2500 / ATV3000
SUPERWINCH: Terra25 / Terra35 / Terra45 / Terra 2500 (SR) / Terra 3500 (SR) / Terra 4500 (SR) / A3500 / LT2000 / UT3000 / LT2500 / LT3000 / LT4000 (SR) / LT4000ATV / LT4000UTV
MILE MARKER: PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
MASTER LOCK: 1500lbs #2955AT requires roller fairlead with a 4.875" bolt pattern
CYCLE COUNTRY: Work Power 1500 and 2500 / Powermax 2500 and 3500
BADLAND, CHAMPION: 2-hole, standard, and wide winches
KEEPER CORP. TRAKKER: KT2500 / KT3000 / KT2500C / KT3000C / KT4000 / KT4000C
KEEPER CORP. TRAKKER: KT2000 requires roller fairlead with a 4.875" bolt pattern
SMITTYBILT: XRC 2.0 requires roller fairlead with a 4.875" bolt pattern
SMITTYBILT: XRC 3.0 / XRC 4.0
XGEAR: X3000 / X4000 4-hole standard (3.00" x 4.875" bolt pattern)
VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (hardcore series) with 3.00" x 4.875" or 3.00" x 6.600" bolt pattern mount-up
Traveller: 1078311 (1078311 will NOT work on 2014-2015 models)
Traveller: 1078088 / 1078302 require roller fairlead with a 4.875" bolt pattern
QUADBOSS: RP25 / RP35
Possibly many others with standard mounting pattern of 4-hole 3.00" x 4.875" bolt pattern with rollers that are 5.876" bolt pattern, 4-hole wide 3.00" x 6.60" bolt pattern, or 2-hole 3.10” with rollers that are 4.875” bolt pattern
